Three optionalDefine an 8 m side with half walls
The 8 m half side wall arrangement uses two 4 × 1 m polyester sections. It leaves the space above the walls open.
White sections are available as a pair, with printed 4 m half walls also offered. Optional 4 m aluminium poles and connectors provide the supports.
Pole and wall details
Poles and connectors
Optional 4 m aluminium poles support the half wall sections. Use 180° connectors for sections side by side, with straight and 90° connectors also available.
White or printed
Choose the pair of white half walls or select 4 m half walls with full-colour printing.
Technical data
|
ITEM |
DESCRIPTION |
SIZE |
WEIGHT |
QTY/CARTON |
CARTON SIZE |
|
7906-W |
2x4m half sidewall white |
4x1m |
– |
||
|
7906-FP |
2x4m half sidewall – Printed |
4x1m |
– |
||
|
7702 |
4m Pole |
4m |
2.6 |
10 |
20x20x163CM |
|
7701-40 |
Connector for 40mm regular |
– |
0.35kg |
30 |
20x31x38CM |
|
7714 |
Connector for 40mm 90° |
– |
0.35kg |
30 |
20x31x38CM |
|
7713 |
Connector for 40mm 180° |
– |
0.35kg |
30 |
20x31x38CM |
Optional – Aluminum pole and 3 models of connectors (straight connector when its only one wall connected, 90 deg when its 2 walls connect together in L shape, 180 deg when its 2 walls connect together side by side (usually for 3×6 or 4×8))
Layout & Technical
